Overview
This investigation explores why different objects feel warmer or colder to the touch. Starts with a collection of different objects that students arrange in order by how warm they feel. Activities continue to help develop the idea that heat energy is transferred by touch from a source to a receiver. Activities provide opportunities for science processes of observation, evidence, variables, measurement, reasoning, evidence, and explanation to be used and discussed.
Big ideas, concepts, facts, and outcomes
Physical Science - Heat Energy, energy transfer, temperature
What science says about the physical world - enduring understanding, big ideas, generalizations.
- Objects feel warmer or colder to the touch.
- We refer to that sensation as temperature.
- The amount of heat energy in an object determines its temperature.
- Heat energy will transfer from warmer objects to colder objects.
Related concepts and facts
- Energy is a property of matter that is related to doing something - heat, chemical change, motion, light, magnetism, nuclear change, electrical.
- Heat can be produced in many ways, such as burning, rubbing, or mixing one substance with another.
- Heat is transferred from a source to a receiver.
- Heat is transferred in predictable ways, flowing from warmer objects to cooler ones, until both reach the same temperature.
- Heat can be transferred during a chemical, electrical, magnetic, light, mechanical, or nuclear reaction.
- Objects that give off light usually give off heat.
- Mechanical energy is usually related to heat through friction.
- Hot and cold objects will transfer heat energy until they reach equilibrium.
- Some materials conduct energy better than others.
- Some materials can transfer heat by contact or at a distance
- Heat is almost always a result of energy transfer.
- Heat can be transferred by touching of particles (collisions of atoms conduction), or through space (by rays radiation) or currents in a fluid (convection).
- Heat energy is the disorderly motion of molecules and in radiation.
- Insulator is a material that has a slower transfer of energy.
- Conductor is a material that easily transfers energy.
Outcome
Heat energy is related to the amount of particle (atom, molecule) movement in a substance.
Specific outcomes -
- Describe energy as ...
- Describes hot and cold as a measure of heat energy.
- Describes temperature increases and decreases as directly related to the amount of heat energy.
- Describes heat energy as directly related to the amount of random motion of the particles (atoms,molecules).
- Describes the transfer of heat energy as a change in the random motion of the particles (atoms, molecules) caused by the touching of objects with different amounts of heat energy.
- Describes the exchange of heat energy as a product of the temperature differences and mass differences of all the objects involved in the exchange.
- Use observation to compare how different surfaces vary: smooth, rough,bumpy, air pockets... can affect the transfer of heat energy.
- Identify surfaces as a variable that changes from object to object.
- Observe the different surfaces and see if there is a clue on how each might relate to how the energy is being transferred.
- Describe the relationship between the kinds of surfaces and the transfer of heat energy.
- Describe and explain that the flow of heat energy between
different surfaces is different depending on the surface of the objects.
- Describe how
heat transfer affects our daily lives and relates to the world in which we live.
Inquiry - processes - variables
(How science inquires - process, skill, methodolgy, practice)
Variables
are conditions that can be changed and that can affect outcomes.
Related concepts and facts
- Variables include, size, shape, temperature, amount, volume, rate, ...
Outcome
Identify variables and describe how they operate to effect other variables. (operational definition).
Specific outcomes -
- Identify variables and suggest how they change.
- Identify different variables and describe how they are
conditions that can be changed and that can affect outcomes.
- Compare variables. (different surfaces with different shapes and properties, made from different materials that have different properties ...
- Combine variables to see if there are patterns or relationships to use as explanations (variables that affect energy transfer).
- Identify variables and describe how they operate to effect other variables. (operational definition).
Inquiry - processes - measurement
(How science inquires - process, skill, methodolgy)
Temperature is the measure of heat energy.
Related concepts and facts
- measurement is a way to make more accurate or better observations
- thermometer is a tool that measures the temperature (heat energy)
- water freezes at 0 degree and boils 100 degrees Celsius
- water freezes at 32 degree and boils 212 degrees Farenheit
Outcome - measurement
Identify variables and describe how they operate to effect other variables. (operational definition).
Specific outcomes -
- States that a thermometer is used to measure temperature.
- Knows the approximate relative temperatures of freezing, room temperature, summer day, and boiling.
- Accurately and safely uses thermometers with different scales to decide an appropriate range or error and measure temperatures from below freezing to boiling.
- Knows how to safely and accurately take appropriate temperature readings and understands that temperature scales are dependent on arbitrary relative references (boiling or freezing) and the degradations one chooses to use between them.
Activities to provide sufficient opportunities for students to attain the targeted outcomes.
Possible Activity Sequence
- Order objects by how cold or warm they feel.
- Discussion
- Take the temperature of the objects
- Discussion
- Temperature and perception
- Look at objects with microscope
- Create a model for possible explanation that explains the observations - both our touching sensations and the observations of the thermometer readings.
Pedagogical ideas
Focus questions:
- What is temperature?
- What makes objects feel warm and cold?
- Why do some things
feel cold and others feel warm?
- How do we determine temperature?
- How can we make better observations?
- How do the observations we make provide more accurate information?
- Could we think of an experiment that we might do to expand our theory of surface shape effecting the transfer of energy?
Scoring guides
Low level: Explains heat with I don't know, or as soemthing with magic like qualities: like heat being a substance continuously generated within the object. Like a blanket, coat, glove, ... generates and gives off heat without consideration of limited supply or conservation of energy.
Middle level: Explains heat energy as something different than the object itself. Something that can be transfered from one thing to another.
High level: Explains heat is transferred in predictable ways from a source to a receiver. Flowing from warmer objects to cooler ones, until both reach the same temperature. Some materials conduct heat energy better than others, which can effect peoples perceptions of temperature.
Activities
Exploration Activities:
Activity: Order objects from hot to cold by touching them
Materials: 6-8 objects with a range of different surfaces that conduct heat energy from poor to real good: cotton ball, metal, plastic, cloth, chalk, and wood block or pencil; thermometer
Suggested procedure:
What is the coolest and warmest of the objects? (Exploration)
Have the collection of objects displayed in the classroom so students can see that they have been there for hours or minutes as appropriate for their coming and going to class. Pass one collection of the similar objects to each group and ask them to arrange the objects from the coolest feeling to the warmest feeling and record the results in their lab notes. Students
should become disequilibrated.
- Have
students organize the objects from hot to cold by touching them
- Discuss
with the group, what in their ordering is similar and different (Did everyone put the metal cube as the coldest? Did everyone put the any other as the warmest?).
- Ask
students why they feel different.
Activity: Temperature and perception
Materials: Three cups, hot water, cold water, and medium water.
Suggested procedure: Place the index finger of your right hand into hot water and the index finger on your left hand into cold water, count to 30, and put both fingers into the medium cup. Students
should become disequilibrated and will begin to move toward equilibrium during these activities or later during the invention activites.
Invention Activities:
Activity: Actual temperature of the objects
Materials: Thermometer
Activity procedure: Take the temperature of each object and write it in your lab notes.
Activity - Look at objects with microscope.
|metal cube | candle | chalk | wood oak block | plastic cube | fabric | styrofoam | cotton |
Surfaces of different objects are different.
Activity: Energy transfer model
Focus question - What causes your finger to feel a temperature difference?
Make a model of the interactions that explain how the temperatures can actually be identical and feel differently.
Write an explanation.
Lab Notes
Select six different kinds of materials that are not near a heat source,
outside window, or in the sunshine. Write a general description to identify
each in a chart. Imagine that you touched each material and predict how
warm or cool it would feel if you touched it. Then actually touch a sample
of each and write your observation of how cool or warm that it actually
felt.
Material |
Prediction |
Observation |
Comments |
1 |
|
|
|
2 |
|
|
|
3 |
|
|
|
4 |
|
|
|
5 |
|
|
|
6 |
|
|
|
- Which type of material felt the warmest?
- Which type of material felt the coldest?
- Order the materials from warmest to coldest?
Warmest
1.
2.
3.
4.
5.
6.
Coldest
Why do think the materials felt different?
A person made the following statement: "The different materials
do not have different temperatures. Each of the materials is about as warm
as all the others even though they felt different." Why do you think
she/he made this statement?
- What evidence could you collect to come to this conclusion?
Hold a thermometer for about one minute on each of the materials and
find all of the temperatures.
- Does the differences match the differences felt?
- What is the air temperature in the room at their original locations?
- What does the data suggest?
Put all the materials in the same place for a period of time. Do you
think they will have the same temperature?
- What do you observe?
- What do you conclude from this additional information?
Is it possible that the difference in the temperature felt is caused
by some other property, beside temperature?
- Another property of the materials?
- What property do you suspect might be involved?
- Could different materials transfer heat at different rates?
- How do the differences in the temperature relate to the kind of material
each is made of?
- For example, does plastic transfer heat less than metal?
- If the plastic would transfer less heat from your hand, then would that
cause it to feel warmer than the metal or colder?
- Would it feel colder the more heat transferred from your hand or warmer?
- Would if feel hotter the more heat transferred from your hand or colder?
- Could the rate of transfer be related to the properties of the different
materials rather than the temperature of the different objects?
- How does the transfer of heat from you hand makes them feel different?
Create a model to explain why the observations - both our touching sensations and the observations of the thermometer readings.
Model diagram:
Extensions
How would you answer the following question posed by a student? "On
a cold day why do the handlebars of my bike feel colder than the handle
grips?"
What kinds of thinking processes did we use to solve the problems.
What processes would scientist say that we used?
Thinking process |
Scientific Process |
How did it help or how did we use it? |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
What feedback from your actions was especially helpful?
